Camera
Image Sensor: 1/2.7 inch CMOS
Max. Resolution: 2880 (H) × 1620 (V)
Pixel: 5MP
Scanning System: Progressive
Electronic Shutter Speed:
PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s
S/N Ratio: >65 dB
Min. Illumination: 0.005 Lux/F1.6, 30IRE, 0 Lux IR on
Illumination Distance: 30 m (98.4 ft)
Illuminator On/Off Control: Auto; manual
Illuminator Number: 3
Pan/Tilt/Rotation Range:
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type: Fixed-focal
Mount Type: M12
Focal Length: 2.8 mm; 3.6 mm
Max. Aperture: F1.6
Field of View:
2.8 mm: 132° × 111° × 58° (diagonal × horizontal × vertical)
3.6 mm: 109° × 92° × 48° (diagonal × horizontal × vertical)
Iris Type: Fixed iris
Close Focus Distance:
2.8 mm: 0.9 m (3.0 ft)
3.6 mm: 1.6 m (5.2 ft)
DORI Distance
Lens:
2.8 mm:
Detect: 63.6 m (208.7 ft)
Observe: 25.4 m (83.3 ft)
Recognize: 12.7 m (41.7 ft)
Identify: 6.4 m (21.0 ft)
3.6 mm:
Detect: 80 m (262.5 ft)
Observe: 32 m (105.0 ft)
Recognize: 16 m (52.5 ft)
Identify: 8 m (26.2 ft)
Video
Frame Rate:
CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps
NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps
AHD:
PAL: 4M@25 fps
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps
NTSC: 4M@30 fps
CVBS:
PAL: 960H
NTSC: 960H
Resolution: 5M (2880 × 1620); 4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480)
Day/Night: Auto switch by ICR
BLC: BLC/HLC/DWDR
WDR: DWDR
White Balance: Auto; manual
Gain Control: Auto; manual
Noise Reduction: 2D NR
Smart IR: Yes
Mirror: Off/On
Privacy Masking: Off/On (8 area, rectangle)
Certifications
CE (EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010+A1:2015, EN 55035:2017, EN 50130-4:2011+A1:2014, EN 62368-1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpart B, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Port
Audio Interface: One channel built-in mic (-A)
Video Output: Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power
Power Supply: 12V ±30% DC
Power Consumption: Max 3.7W (12V DC, IR on)
Environment
Operating Temperature: -40°C to +60°C (-40°F to 140°F); 95% (non-condensation)
Storage Temperature: -40°C to +60°C (-40°F to 140°F); 95% (non-condensation)
Protection Grade: IP67
Structure
Casing: Plastic throughout the whole casing
Camera Dimensions: 161.3mm×69.7mm×70.0mm (6.35"×2.75"×2.75")
Net Weight: 0.19 kg (0.55 lb)
Gross Weight: 0.29 kg (0.64 lb)
